PS69.AXCSABHXAMKRX VEGA Level Meter Radar Sensor For Continuous Level Measurement

Name: PS69AXCSABHXAMKRX VEGA Level Meter Radar Sensor For Continuous Level Measurement
Brand: vega
Price: 1 USD

Quality PS69.AXCSABHXAMKRX VEGA Level Meter Radar Sensor For Continuous Level Measurement for sale

Brand Name : vega

Model Number : PS69.AXCSABHXAMKRX

Place of Origin : DE

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T

Supply Ability : 500pcs/month

Delivery Time : On request

Packaging Details : Original packing

Approval : for Ex-free area

Electronics : Two-wire 4 ... 20 mA/HART

Supplementary electronics : without

Housing / Protection : Aluminium single chamber / IP66/IP68 (0.2bar)

Max. measuring range : 120m

HS code : 90318080

Contact Now

PS69.AXCSABHXAMKRX VEGA Level Meter Radar Sensor For Continuous Level Measurement Of Bulk Solids

Technical specifications

Measuring range - Distance

120 m [Meter - Foot]

Process temperature

-40 ... 200 °C [°C - °F]

Process pressure

-1 ... 20 bar [Bar - kPa - psi]

Accuracy

± 5 mm / ± 0.2"

Frequency

80 GHz

Beam angle

≥ 3,5°

Version

with plastic horn antenna ø 80 mm

Metal jacketed lens antenna

Materials, wetted parts

316L

PEEK

Threaded connection

G1½, 1½ NPT

Flange connection

≥ DN80, ≥ 3"

Seal material

EPDM

FKM

Housing material

Plastic

Aluminium

Stainless steel (precision casting)

Stainless steel (electropolished)

Protection rating

IP66/IP68 (0,2 bar)

IP66/IP67

IP66/IP68 (1 bar)

Output

Profibus PA

Foundation Fieldbus

4 … 20 mA/HART - two-wire

Modbus

4 … 20 mA/HART - four-wire

Ambient temperature

-40 ... 80 °C

Application area

Special advantages are the small process fittings for small vessels or tight spaces. The very good signal focusing allows use in large silos or vessels with many internal installations.

The VEGAPULS 69 is a sensor for continuous measurement of bulk solids under different process conditions. It is ideal for level measurement in very high silos, large bunkers and segmented vessels. Thanks to the very good signal focussing a simple setup and reliable measurement is ensured. The VEGAPULS 69 can be equipped with an encapsulated plastic antenna or a lens antenna integrated in the metal flange. This enables the optimum adaption to different application areas.

Your benefit

High plant availability, because wear and maintenance-free
Maintenance-free operation through non-contact measuring principle
Reliable measurement independent of vapour, dust and noise
